IDP T4 S363SXE Complete Kit

$3,025.00

-

  • $0.00
  • –
  • –
  • Total –

Description

Product Description

The Irate Diesel 7.3 Powerstroke T4 turbo kit with the BorgWarner S363SXE is a complete IDP T4 mounting system with 304 stainless up-pipes and intercooler piping, plus the S363SXE turbo. Just hook up your air filter and exhaust and it’s ready to run.

It’s built for owners targeting roughly 300-500hp, with very good driving characteristics, our fastest spool of the T4 kits (around 1400 RPM), and excellent towing performance. It works with stock injectors up to 30% over stock nozzle injectors.

Who It’s For

  • Manual transmission trucks with stock fuel and injectors no larger than 205/30
  • Automatic trucks: We suggest the 364.5 instead, since the converter helps keep that turbo spooled

Why the S363SXE

  • Fastest spool of our T4 kits, around 1400 RPM
  • Excellent towing manners
  • 360° thrust bearing for durability
  • Forged milled compressor wheel
  • Integrated speed sensor port and pre-machined boost port
  • Optimized compressor cover aerodynamics
  • Flexible compressor cover outlet options
  • Part of BorgWarner’s S300SX-E series, their newest SX-E line

What’s in the Kit

  • Complete IDP T4 mounting system
  • 304 stainless steel up-pipes
  • 304 stainless steel intercooler piping
  • BorgWarner S363SXE turbo
  • 2.5-3″ boot for compressor outlet

Choose Your Truck Year

Select your truck’s year when ordering.

  • 1994-1997 and 1999 E-Series trucks: Add plenums to your order.
  • 1999.5-2003 trucks: You can use existing plenums, but we don’t recommend it.

1994-1997 OBS Requirements


FAQ

How much power does this kit support?
Around 300-500hp.

How fast does it spool?
Around 1400 RPM, the fastest of our T4 kits.

Does it work with stock injectors?
Yes, up to 30% over stock nozzle injectors.

Is it right for my automatic truck?
We suggest the 364.5 for automatics, since the converter helps keep that turbo spooled. The S363SXE is best for manual trucks with stock fuel and injectors up to 205/30.

Does it include intercooler piping?
Yes, 304 stainless. You’ll need an intercooler to run it.

Is the turbo included?
Yes. The kit includes the BorgWarner S363SXE.

What do I need for my truck year?
94-97 and 1999 E-Series trucks need plenums. 94-97 trucks also need an electric fuel system.

NEW Install instructions

  • Turbo Kit Parts list
    1 Pedestal OBS/SD
    1 L Bracket OBS/SD
    1 Bellowed Up-pipe Assembly OBS/SD
    1 Braided Oil supply line OBS/SD
    1 Stainless Oil drain line OBS/SD
    1 Aluminum turbo drain flange OBS/SD
    1 Aluminum valley drain flange W/O-ring OBS/SD
    1 Stainless Intake Y OBS/SD
    1 Intercooler pipes, SD 2 pipes. OBS 3 pipes OBS/SD
    1 4” stainless intake pipe OBS/SD
    1 Downpipe lower and upper section OBS 3”, SD 4”. OBS/SD
    1 4” V-band clamp SD downpipe upper to lower connection SD
    1 3.5” or 4” v-band for S300 or S400 style turbo OBS/SD
    1 Band clamp for 2 piece OBS downpipe connection OBS
    1 Compressor intake boot. 4” for S300, 5” for S400 & 5.5” for Race cover. OBS/SD
    2 Clamps for intake boot to turbo and intake pipe. OBS/SD
    1 3/8”NPT X 10JIC 45* fitting OBS/SD
    1 1/2”NPT x 10JIC 45* fitting OBS/SD
    1 1/8”NPT x 6JIC straight fitting OBS/SD
    1 1/4”NPT x 6JIC straight fitting OBS/SD
    1 3/8″ plug for intake Y, not used on SD OBS
    1 Pedestal O-rings OBS/SD
    9 M8 flange bolts for pedestal and up-pipes OBS/SD
    4 M10 studs with flat washers and nuts OBS/SD
    4 M8x40 flange bolts and locking flange nuts, up-pipe to manifold. OBS/SD
