This turbo has been used as a single in race only applications with good results but is recommended as the low pressure for a compound set up.
- Twin hydrodynamic journal bearings
- Extended tip technology compressor wheel
- Forged Milled Wheel Technology (Billet Aluminum)
- Compressor cover recirculation grooves
- Optimized compressor inlet geometry
- Race Cover Standard
- Adjustable compressor and turbine housing orientation
- Twin scroll turbine housing
- T4 Turbine Footprint
BW Part Number: 179182
You may also choose an additional turbine housing A/R. NOTE: Turbo already comes with a turbine housing as listed on the above chart. If you would like a different turbine housing, you must purchase an additional housing from the below chart.
Oil feed port is 1/4NPT and oil drain is standard T3/T4 flange
